Pressure Pro Pro-Skid Series Power Unit Direct Drive TS/D4040HG431

Pressure Pro Pro-Skid Series Power Unit Direct Drive TS/D4040HG431

–MACHINE ONLY. SKID AND TANK SOLD SEPARATELY–

Pro-Skid Series

Pro-Skid units can be combined with various cold water pump/engine units to achieve a “Totally Self Contained” 100- or 200-gallon tank feed system. Available pressures of 2400 PSI to 4000 PSI and flow rates up to 10 GPM in belt-, gear-, and direct-drive configurations. Add the tank/skid model with desired equipment options listed to design a custom Honda-powered unit built to your specifications. All skids are constructed of aircraft-grade aluminum which is chemical resistant and rustproof. All units feature an adjustable pressure unloader valve. These skid units mount quickly and securely into truck beds, trailers or other vehicles.

Standard Accessories

• Gun/wand assembly w/ quick connects
• 50′ high-pressure hose w/ quick connects
• The chemical injector assembly w/ quick connects
• 4 color-coded QC spray nozzles
• 1 color-coded QC chemical nozzle

NOTE: All 100-gallon units are factory assembled (200-gallon units require minor assembly), tested in the USA, and delivered ready to operate. GX630 Model comes with remote 6-gallon poly fuel tank – Non-Carb Evaporative Compliant – Not for sale to California – See options below for California compliant upgrade

-pictured reel and reel rack are sold separately

–AST050, AST100, OR AST200 TANK, ALUMINUM SKID & INLET PLUMBING KIT IS REQUIRED FOR THE PRO SKID–

Pressure Washer Power Units
Part #	GPM	PSI	Model/Brand	Pump
TS/D3024HG432	3.0	2400	GX200 Honda	GP Direct Drive
TS/D3027HG432	3.0	2700	GX200 Honda	GP Direct Drive
TS/D3032HG431	3.0	3200	GX270 Honda	GP Direct Drive
TS/D4040HA431	4.0	4000	GX390 Honda	AR Direct Drive
TS/D4040HG431	4.0	4000	GX390 Honda	GP Direct Drive
TS/VB4040HG431	4.0	4000	GX390 Honda	HP V-Belt Drive
TS/VB5535HGEA431	5.5	35000	GX630 Honda	HP V-Belt Drive
