Pressure Pro Pro-Max HP series 230v ELECTRIC Polychain Drive Pressure Washer B4030E1G403
Standard Accessories
- Gun/wand assembly w/ quick connects
- 50′ high-pressure hose w/ quick connects
- The chemical injector assembly w/ quick connects
- 4 color-coded QC spray nozzles
- 1 color-coded QC chemical nozzle
Available Options
- Skid Mount – Precede model with S/ Example: S/B5535E3G303
- Block Mounted K7 Unloader
- 3500 psi max
- Auto Start/Stop (230V)
- Auto Start/Stop w/ time delay-consult factory
- 460V available – consult factory
NOTE: Review specs for models with Auto Start/ Stop options as these units are custom made and NONCANCELABLE & NONRETURNABLE.
Standard Features
- Revolutionary aircraft grade aluminum frame with dual handles (no welds to fail)
- Lifetime frame warranty
- Easy access tip holder/gun holder/hose hanger on handle
- Epoxy powder coated finish
- 10,000 hour rated Gates poly chain cogged belt (two-year warranty)
- 50 mesh inlet water filter
- Adjustable pressure unloader
- Oversize pneumatic tires
- Dual spring cushioned shock-absorbing feet
- 3/4″ cold-rolled steel threaded axle
- Low-speed pump and thermo-sensor (prevents overheating in bypass mode)
- TEFC Commercial/Industrial motors
- Mag Starter assembly, w/ thermal overload, and start/stop buttons in NEMA enclosure w/ 12′ power cord (no plug)
NOTE: 8 GPM units set up for tank feed.
Pro-Max Series Electric, Polychain | |||||
|---|---|---|---|---|---|
| Part # | GPM | PSI | HP | Volts/Phase/Amps | Pump |
| B4020E1A403 | 4.0 | 2000 | 5.0 | 230V/1PH/25A | AR |
| B4020E1CP407 | 4.0 | 2000 | 5.0 | 230V/1PH/25A | CAT |
| B4020E1G403 | 4.0 | 2000 | 5.0 | 230V/1PH/25A | GP |
| B4020E3A403 | 4.0 | 2000 | 5.0 | 230V/3PH/12A | AR |
| B4020E3CP407 | 4.0 | 2000 | 5.0 | 230V/3PH/12A | CAT |
| B4020E3G403 | 4.0 | 2000 | 5.0 | 230V/3PH/12A | GP |
| B4030E1A403 | 4.0 | 3000 | 7.5 | 230V/1PH/33A | AR |
| B4030E1CP407 | 4.0 | 3000 | 7.5 | 230V/1PH/33A | CAT |
| B4030E1G403 | 4.0 | 3000 | 7.5 | 230V/1PH/33A | GP |
| B4030E3A403 | 4.0 | 3000 | 7.5 | 230V/3PH/17A | AR |
| B4030E3CP407 | 4.0 | 3000 | 7.5 | 230V/3PH/17A | CAT |
| B4030E3G403 | 4.0 | 3000 | 7.5 | 230V/3PH/17A | GP |
| B4035E3A403 | 4.0 | 3500 | 10.0 | 230V/3PH/23A | AR |
| B4035E3CP407 | 4.0 | 3500 | 10.0 | 230V/3PH/23A | CAT |
| B4035E3G403 | 4.0 | 3500 | 10.0 | 230V/3PH/23A | GP |
| B5535E3A403 | 5.5 | 3500 | 15.0 | 230V/3PH/34A | AR |
| B5535E3G403 | 5.5 | 3500 | 15.0 | 230V/3PH/34A | HP |
| B8035E3G100 | 8.0 | 3500 | 20.0 | 230V/3PH/46A | GP |
| B4040E3A403 | 4.0 | 4000 | 15.0 | 230V/3PH/34A | AR |
| B4040E3G403 | 4.0 | 4000 | 15.0 | 230V/3PH/34A | HP |
| B4540E3C407 | 4.5 | 4000 | 15.0 | 230V/3PH/34A | CAT |
