Pressure Pro Hot Shot Series Gas Pressure Washer 4012-10A

Pressure Pro Hot Shot Series Direct Drive Pressure Washer 4012-10A

Standard Accessories

• Gun/wand assembly with insulated grip and quick connects
• 50′ high-pressure hose w/ quick connects
• Maxi-Flo 20% chemical injector assembly w/ quick connects
• 4 color-coded QC spray nozzles
• 1 color-coded QC chemical nozzle

Standard Options

• ATK005 Adjustable Thermostat
• BRK100 Brake Kit
• HRK415 Hose Reel Kit, 150′ x 3/8″ max. w/ no add’l hose
• MC-B135 Machine Cover Blue Poly Marine Fabric

NOTE: AR, CAT, and VIPER gear drive pumps available – consult factory.

Standard Features

• Rugged powder-coated steel roll cage frame w/ lifting hook & 13” flat-free tires & threaded axles
• 4-wheel dimensions: 39” L x 31” W x 49” H
• Super efficient schedule 80 coil w/ one-piece molded insulation combustion chamber
• Stainless steel coil wrap
• 8-gallon poly diesel fuel tank w/ fuel filter
• Commercial/Industrial grade engines
• Reliable Beckett burners
• High limit over-temp protection
• Safety pressure relief valve
• Thermo-sensor (prevents overheating in bypass mode)

NOTE: Gasoline Honda and Diesel-powered models include electric start, and battery w/ marine battery box.

4 Wheel Portable Direct Drive Gas Engine 12V Models
Part #	GPM	PSI	Model/Band	Pump
4012-10A	4.0	4000	GX390 Honda	AR
4012-10C	4.0	4000	GX390 Honda	CAT
4012-10G	4.0	4000	GX390 Honda	GP
4012-10KG	4.0	4000	CH440 Kohler	GP
4012-42HV	4.0	4200	GX390 Honda	VIPER
4012-42KV	4.0	4200	CH440 Kohler	VIPER

4 Wheel Portable V-Belt Drive Gas Engine 12V Models
Part #	GPM	PSI	Model/Brand	Pump
4012-17A	4.0	4000	GX390 Honda	AR
4012-17C	4.0	4000	GX390 Honda	CAT
4012-17G	4.0	4000	GX390 Honda	HP
