Pressure Pro Hot Shot Series 230v ELECTRIC Direct Drive Pressure Washer 3230-30A1
Standard Features
- Rugged powder-coated steel roll cage frame w/ lifting hook & 13” flat-free tires & threaded axles
- 4-wheel dimensions “39” L x 31” W x 49” H
- Super efficient schedule 80 coil w/ one-piece molded insulation combustion chamber
- Stainless steel coil wrap
- 8-gallon poly diesel fuel tank w/ fuel filter
- Commercial/Industrial grade motors
- Reliable Beckett burners
- High limit over-temp protection
- Low-speed pump w/ thermo-sensor (prevents overheating in bypass mode)
- Safety pressure relief valve
- 12′ power cord (no GFCI or Plug)
NOTE: All units are completely factory assembled, tested in the USA, and delivered ready to operate.
4 Wheel Portable Direct Drive Electric Models | |||||
|---|---|---|---|---|---|
| Part # | GPM | PSI | HP | Volts/Phrase/Amps | Pump |
| 3230VB-25G1 | 3.0 | 2500 | 5.0 | 230V/1PH/25A | GP |
| 4230VB-20C1 | 4.0 | 2000 | 5.0 | 230V/1PH/25A | CAT |
| 4230VB-20G1 | 4.0 | 2000 | 5.0 | 230V/1PH/25A | GP |
| 4230VB-20G3 | 4.0 | 2000 | 5.0 | 230V/3PH/12A | GP |
| 5230VB-15G1 | 5.0 | 1500 | 5.0 | 230V/1PH/25A | GP |
| 4230VB-30C1 | 4.0 | 3000 | 7.5 | 230V/1PH/33A | CAT |
| 4230VB-30G1 | 4.0 | 3000 | 7.5 | 230V/1PH/33A | GP |
| 4230VB-30G3 | 5.0 | 3000 | 7.5 | 230V/3PH/17A | GP |
| 5230VB-20G1 | 4.0 | 2000 | 7.5 | 230V/1PH/33A | GP |
| 4230VB-35G1 | 4.0 | 3500 | 10.0 | 230V/1PH/46A | HP |
| 4230VB-35G3 | 4.0 | 3500 | 10.0 | 230V/3PH/23A | HP |
| 5230VB-30G1 | 5.0 | 3000 | 10.0 | 230V/1PH/46A | HP |
| 5230VB-30G3 | 5.0 | 3000 | 10.0 | 230V/3PH/23A | HP |
